品牌merit sensor
型号m11-0015-11
压力类型表压
工作压力0.15psi
输出类型模拟输出
输出电压3.3
精度0.25%
系列m11-0015-11
电源电压5v
端口类型双口
工作温度150℃
封装/外壳直插
特性压力传感器
最小包装数10
应用领域测量仪器
展开
供应merit sensor无损检测中低压表贴压力传感器m11-0015-11
点我去除广告
the ms series is a surface-mountable pressure monitoring device suitable
for low to medium pressure applications ms系列是一种适用于表面安装的压力监测设备适用于中低压应用
ms系列是一种可安装在表面上的设备，适用于大容量和中低压应用。
特征
范围15至500 psi（1至34.5 bar; 103至3,447 kpa）
typeabsolute，gage，differential和vacuum
mediaclean，干燥空气和非腐蚀性气体
packagingbulk
灵活性灵敏度，阻力，桥梁，约束等

merit sensor是压阻式压力传感领域的领导者，与客户合作，为各种应用和行业创建高性能解决方案。
sentium：merit sensor产品采用专有的sentium?技术，可提供同类的工作温度范围（-40°c至85°c）和出色的稳定性。
技术：merit sensor采用压阻式惠斯通电桥设计，将玻璃阳极键合到化学蚀刻的硅膜上。 所有产品均符合rohs标准。
功能：merit sensor设计，工程师，制造，切割，组装，测试，销售和服务来自犹他州盐湖城附近进设施的模具和包装产品
features
range 15 to 500 psi (1 to 34.5 bar; 103to 3,447 kpa)
type absolute, gage
media clean, dry air and non-corrosive gases
packaging substrates, covers, gels, etc.
flexibility sensitivity, resistance, bridge, constraint, etc.
benefits
performance enjoy best-in-class performance due to merit’s
proprietary sentium technology.
cost save money over time with high-performing die
security feel confident doing business with an experienced
company backed by a solid parent company
(nasdaq: mmsi)
speed get to market quickly with creative and
flexible solutions.
service experience prompt, personal, and
professional support.


merit sensor
北京盛思瑞特传感技术有限公司
联系人：唐先生 18301092563
qq:2355647912
e-mail:2355647912@qq.com
地址：北京市昌平区振兴路28号绿创科技大厦b520
