商品详情
- 高达 1 GHz 的内部分析带宽和高达 5 GHz 的外部分析带宽有助于对 5G 和车载雷达等需要占用大带宽的新兴标准进行分析
- 在高达 110 GHz 的频率范围内执行连续扫描
- 凭借 -150 dBm/Hz（> 50 GHz）的 DANL，可以捕获更低电平的杂散信号
- 高达 255 MHz 的无缝数据流功能可对真实环境中的信号进行记录和分析
- 与 X 系列应用软件兼容，使您可以简化复杂的测量，并提供可重复的结果
- 可检测短仅 3.51 μs 的信号
- 14.1 英寸显示屏可显示更多信息，助您进一步完善自身设计
N9041B N9041B信号分析仪是德N9041B N9041B 租赁N9041B
N9041B N9041B信号分析仪是德特点
N9041B N9041B信号分析仪是德利用我们信号分析平台实现您的下一个突破
我们的 UXA 信号分析仪性能卓越，让您能够表征当今特别具有挑战性的信号，包括 5G、802.11ax/ay、卫星、雷达、电子战（EW）等应用中的快速跳频、宽带和瞬态信号。 优异的相位噪声性能和宽广的无杂散动态范围让可以您深入了解设计纯度。
N9030A 20H-3.6/7.0/13.6/26.5 PXA信号分析仪
N9020A 20H-3.6/7.0/13.6/26.5 EXA信号分析仪
N9010A 20H-3.6/7.0/13.6/26.5 EXA信号分析仪
N9020B MXA 信号分析仪，10 Hz 至 50 GHz
N9030B PXA 信号分析仪，2 Hz 至 50 GHz
N9040B UXA 信号分析仪，2 Hz 至 50 GHz
N9010B EXA信号分析仪，10HZ至44G
理解真实环境中的信号分析（频谱分析）特性
您可以结合使用 UXA 信号分析仪（频谱分析仪）、X-COM 记录器和 PathWave 矢量信号分析（89600 VSA）软件，打造一个直观的测试平台。 这个平台可以捕获和分析雷达和电子战系统中几分钟、几小时乃至数天的实际信号特性，因此您不会错过任何细节。 通过 89600 VSA 软件，您可以对海量数据进行筛选和分析，找出您需要关注的重要事件。
Bandwidth
| N9041B-H1G | Analysis bandwidth, 1 GHz | |
| N9041B-B25 | Analysis bandwidth, 25 MHz (standard) | |
| N9041B-B40 | Analysis bandwidth, 40 MHz |
Calibration
| N9041B-A6J | ANSI Z540 compliant calibration | |
| N9041B-AMG | Calibration + Uncertainties + Guardbanding (Accredited) | |
| N9041B-UK6 | Commercial calibration test data |
Connector Options
| N9041B-ALV | Auxiliary log video output | |
| N9041B-CRP | Connector rear, programmable IF output | |
| N9041B-CRW | Connector, IF out, wide | |
| N9041B-YAV | Screen video, log video and linear video |
Frequency Range
| N9041B-590 | Frequency Range, 2 Hz to 90 GHz | |
| N9041B-5CX | Frequency Range, 2 Hz to 110 GHz |
Performance Features
| N9041B-EA3 | Electronic attenuator, 3.6 GHz | |
| N9041B-EDC | External digitizer control |
Preamplifier
| N9041B-P50 | Preamplifier, 50 GHz |
Security Features
| N9041B-SF1 | Security features, exclude launching programs | |
| N9041B-SF2 | Security features, prohibit saving results | |
| N9041B-SS1 | Additional removable solid state drive, Win10, for PC6S |
Accessories
| 1DVR001A | ROM/CD-R/RW drive | |
| 1MSE001A | Mouse | |
| MLP001A | Minimum loss pad, 50 to 75 ohm | |
| N9041B-2CM | Rack mount flange kit 265.9mm H (6U) - two flange brackets, two standard rails | |
| N9041B-2CP | Rack mount flange and handle kit 265.9mm H (6U) - two brackets, handles, rails |
Application Software with Subscription
| N6141EM0E | EMI Measurement Application | |
| N9061EM0E | Remote Language Compatibility Measurement Application | |
| N9062EM0E | SCPI Language Compatibility Measurement Application | |
| N9063EM0E | Analog Demodulation Measurement Application | |
| N9067EM0E | Pulse Analysis Measurement Application | |
| N9068EM0E | Phase Noise Measurement Application | |
| N9069EM0E | Noise Figure Measurement Application | |
| N9071EM0E | GSM/EDGE/Evo Measurement Application | |
| N9073EM0E | W-CDMA/HSPA+ Measurement Application | |
| N9077EM0E | WLAN 802.11a/b/g/j/p/n/af/ah Measurement Application | |
| N9077EM1E | WLAN 802.11ac/ax Measurement Application | |
| N9080EM0E | LTE and LTE-Advanced FDD Measurement Application | |
| N9080EM3E | NB-IoT and eMTC FDD Measurement Application | |
| N9081EM0E | Bluetooth (TM) Measurement Application | |
| N9082EM0E | LTE and LTE-Advanced TDD Measurement Application | |
| N9084EM0E | Short Range Communications and IoT Measurement Application | |
| N9085EM0E | 5G NR Measurement Application | |
| N9041RT1B | Real-time analysis up to maximum available BW, Basic Detection | |
| N9041RT2B | Real-time analysis up to maximum available BW, Optimum Detection | |
| N90EMEMCB | Basic EMC Functionality | |
| N90EMFP2B | Fast power | |
| N90EMRBEB | Resolution Bandwidth Extended | |
| N9054EM0E | Vector Modulation Analysis Digital Demodulation Measurement Application | |
| N9054EM1E | Vector Modulation Analysis Custom OFDM Application | |
| N9080EM4E | LTE V2X measurement application | |
| N9072EM0E | cdma2000 measurement application, remote control only | |
| N9076EM0E | 1xEV-DO measurement application, remote control only | |
| N9079EM0E | TD-Scdma/HSPA measurement application, remote control only | |
| 89601301C | Multi-vendor hardware connectivity | |
| 89601AYAC | Digital demodulation analysis | |
| 89601B7NC | 3G modulation analysis | |
| N9055EM0E | Power Amplifier Measurement Application | |
| 89601200C | Basic vector signal analysis and hardware connectivity | |
| 89601B7RC | Wireless connectivity modulation analysis | |
| 89601BHFC | Custom OFDM modulation analysis | |
| 89601BHGC | LTE/LTE-A FDD modulation analysis | |
| 89601BHHC | LTE/LTE-A TDD modulation analysis | |
| 89601BHMC | DOCSIS modulation analysis | |
| 89601BHNC | 5G NR modulation analysis | |
| 89601BHPC | FMCW radar analysis | |
| 89601BHQC | Pulse analysis | |
| 89601BHTC | IoT modulation analysis | |
| 89601BHXC | High throughput WLAN modulation analysis | |
| N90EMPSMB | Power Suite Measurement Application | |
| 89601PSMC | Power Suite Measurement | |
| N9085EM4E | NR V2X Measurement Application | |
| N9077EM2E |
WLAN 802.11be Measurement Application |
Bundle Adjustment Option
| N9041B-890 | N9041BM bundle configuration adjustment | |
| N9041B-891 |
N9041BP bundle configuration adjustment |
